Learn by doing. Theory is nice but nothing replaces actual experience.
– Tony Hsieh
By now you should have installed Xcode and some understandings of Swift. If you have skipped the first two chapters, please stop here and go back to read them. You need to have Xcode 10 installed in order to work on all exercises in this book.
You may have heard of the 'Hello World' program if you have read any programming book before. Hello World is a program for the first-time programmer to create. It's a very simple program that outputs 'Hello, World' on the screen of a device. It's a tradition in the programming world. Let's follow the programming tradition and create a 'Hello World' app using Xcode.
Despite its simplicity, the 'Hello World' program serves a few purposes:
- It gives you an overview of the syntax and structure of Swift, the new programming language of iOS.
- It also gives you a basic introduction to the Xcode environment. You'll learn how to create an Xcode project and lay out your user interface using Interface Builder. Even if you've used Xcode before, you'll learn what's new in the latest version of Xcode.
- You'll learn how to compile a program, build the app and test it using the built-in simulator.
- Lastly, it makes you think programming is not difficult. I don't want to scare you away from learning programming. It'll be fun.
Your First App
Your first app, as displayed in figure 3-1, is very simple and just shows a 'Hello World' button. When a user taps the button, the app shows a welcome message. That's it. Extremely simple but it helps you kick off your iOS programming journey.
But this is just a start. After going through the challenges in this chapter, you will keep improving your first app to make it more interesting. To give you a sneak peak, figure 3-2 is your final deliverable.
When you're building your first app, I want you to keep one thing in mind: forget about the code and keep doing. Even though you now have some basic knowledge of Swift, I'm quite sure that you will find some of the code difficult to understand. No worries. Just focus on the exercises, and get yourself familarized with the Xcode environment. We will talk about the code in the next chapter.
Let's Jump Right Into the Project
First, open Xcode. Once launched, Xcode displays a welcome dialog. From here, choose 'Create a new Xcode project' to start a new project.
Xcode shows various project templates for selection. Each template serves different purposes and help you easier to get started with the development of a particular type of application. Say, if you want to develop a sticker pack for the Messages app, you will use the Sticker Pack App template. However, in most case, the Single View Application template is good enough for creating an iOS app. So, choose iOS > Single View Application and click Next.
This brings you to the next screen to fill in all the necessary options for your project.
You can simply fill in the options as follows:
Product Name: HelloWorld – This is the name of your app.
Team: Just leave it as it is. You do not set the team yet. For your first app, just skip this step.
Organization Name: AppCoda – It's the name of your organization. If you are not building the app for your organization, use your name as the organization name.
Organization Identifier: com.appcoda – It's actually the domain name written the other way round. If you have a domain, you can use your own domain name. Otherwise, you may use 'com.
Bundle Identifier: com.appcoda.HelloWorld - It's a unique identifier of your app, which is used during app submission. You do not need to fill in this option. Xcode automatically generates it for you.
Language: Swift – Xcode supports both Objective-C and Swift for app development. As this book is about Swift, we'll use Swift to develop the project.
Use Core Data: [unchecked] – Do not select this option. You do not need Core Data for this simple project. We'll explain Core Data in later chapters.
Include Unit Tests: [unchecked] – Do not select this option. You do not need unit tests for this simple project.
Include UI Tests: [unchecked] – Do not select this option. You do not need UI tests for this simple project.
Click 'Next' to continue. Xcode then asks you where to save the 'HelloWorld' project. Pick any folder (e.g. Desktop) on your Mac. You may notice there is an option for source control. Just deselect it. We do not need to use the option in this book. Click 'Create' to continue.
After you confirm, Xcode automatically creates the 'Hello World' project. The screen will look like the screenshot shown in figure 3-7.
Familiarize Yourself with Xcode Workspace
Before we start to implement the Hello World app, let's take a few minutes to have a quick look at the Xcode workspace environment. In the left pane is the project navigator. You can find all your project files in this area. The center part of the workspace is the editor area. You do all the editing stuff here (such as editing the project setting, source code file, user interface) in this area.
Depending on the type of file, Xcode shows you different interfaces in the editor area. For instance, if you select ViewController.swift in the project navigator, Xcode displays the source code in the center area (see figure 3-8).
If you select Main.storyboard, which is the file for storing user interface, Xcode shows you the visual editor for storyboard (see figure 3-9).
The rightmost pane is the utility area. This area displays the properties of the file and allows you to access Quick Help. If Xcode doesn't show this area, you can select the rightmost button in the toolbar (at the top-right corner) to enable it.
The middle view button of the view selector is deselected by default. If you click on it, Xcode displays the debug area right below the editor area. The debug area, as its name suggests, is used for showing debug messages. We'll talk about that in a later chapter, so don't worry if you do not understand what each area is for.
Run Your App for the First Time
Until now, we haven't written a single line of code. Even so, you can run your app using the built-in simulator. This will give you an idea how to build and test your app in Xcode. In the toolbar you should see the Run button.
The Run button in Xcode is used to build an app and run it in the selected simulator. By default, the Simulator is set to iPhone 8 Plus. If you click the iPhone 8 Plus button, you'll see a list of available simulators such as iPhone 8 and iPhone X. Let's select iPhone 8 as the simulator, and give it a try.
Once selected, you can click the Run button to load your app in the simulator. Figure 3-12 shows the simulator of an iPhone 8.
A white screen with nothing inside?! That's normal. So far we haven't designed the user interface or written any lines of code. This is why the simulator shows a blank screen. To terminate the app, simply hit the *Stop* button in the toolbar.Try to select another simulator (e.g. iPhone X) and run the app. You will see another simulator showed up on screen. Since the release of Xcode 9, you are allowed to run multiple simulators simultaneously.The simulator works pretty much like a real iPhone. You can click the home button to bring up the home screen, and it comes with some built-in apps. Just play around with it to familiarize yourself with Xcode and simulator environment.### A Quick Walkthrough of Interface BuilderNow that you have a basic idea of the Xcode development environment, let's move on and design the user interface of your first app. In the project navigator, select the `Main.storyboard` file. Xcode then brings up a visual editor for storyboards, known as Interface Builder.The Interface Builder editor provides a visual way for you to create and design an app's UI. Not only can you use it to design individual view (or screen), the Interface Builder's storyboard designer lets you lay out multiple views, and chain them together using different types of transitions, so as to create the complete user interface. All these can be done without writing a line of code.In Xcode 10, Apple has made a change to the Object library. If you've used Xcode 9 (or earlier version) before, the Object library was situated at the lower right pane. Now the Object library is hidden by default. You have to click the Object library button at the top menu, as displayed in figure 3-14, to make it appear as a floating window.The Object library contains all the available UI objects such as button, label, image view for you to design your user interface. You can view the Object library in two difference modes: *list view* and *icon view*. I prefer to use icon view in this book. But if you want to change to the list view mode, simply use the toggle button to switch between them.Since we chose to use the *Single View Application* template during project creation, Xcode generated a default view controller scene in the storyboard. In your Interface Builder, you should see a view controller in the editor area. This view controller is where you design the app's user interface. Each screen of an app is usually represented by a view controller. Interface Builder allows you to add multiple view controllers to the storyboard and link them up. Later in this book, we will further discuss about that. Meanwhile, focus on learning how to use Interface Builder to lay out the UI for the default view controller.The Document Outline view of the Interface Builder editor shows you an overview of all scenes and the objects under a specific scene. The outline view is very useful when you want to select a particular object in the storyboard. If the outline view doesn't appear on screen, use the toggle button (see figure 3-14) to enable/disable the outline view.
Lastly, there is a configuration bar in the Interface Builder. To reveal the bar, place the mouse cursor on View as: iPhone 8, and then single-click on it. The configuration bar was first introduced in Xcode 8 that lets you live preview your app UI on different devices. Furthermore, you can use the + and - buttons to zoom in/out the storyboard. We will talk about this new feature later on.
Designing the User Interface
Now we are going to design the app's user interface. First, we will add a Hello World button to the view. Click the Object library button to shows the Object library. You can then choose any of the UI objects, and drag-and-drop them into the view. If you're in the icon view mode of the Object library, you can click on any of the objects to reveal the detailed description.
Okay, it's time to add a button to the view. All you need to do is drag a Button object from the Object library to the view.
As you drag the Button object to the view, you'll see a set of horizontal and vertical guides if the button is centered. Stop dragging, and release your button to place the Button object there.
Next, let's rename the button. To edit the label of the button, double-click it and name it 'Hello World'. After the change, you may need to center the button again.
In case the words are truncated, you can resize the button to make it fit or press command+= to let Xcode resize it for you.
Great! You're now ready to test your app. Select the iPhone 8 simulator and hit the Run button to execute the project, you should see a Hello World button in the simulator as shown in figure 3-19. Cool, right?
However, when you tap the button, it shows nothing. We'll need to add a few lines of code to display the 'Hello, World' message.
Coding the Hello World Button
Swift Ios Example
Now that you've completed the UI of the HelloWorld app, it's time to write some code. In the project navigator, you should find the ViewController.swift file. Because we initially selected the Single View Application project template, Xcode already generated a ViewController class in the ViewController.swift file. This file is actually associated with the view controller in the storyboard. In order to display a message when the button is tapped, we'll add some code to the file.
Select the ViewController.swift file and the editor area immediately displays the source code. Type the following lines of code in the ViewController class:
Your source code should look like this after editing:
What you have just done is added a showMessage(sender: UIButton) method in the ViewController class. The Swift code within the method is new to you. I will explain it to you in the next chapter. Meanwhile, just consider the showMessage(sender: UIButton) as an action. When this action is called, the block of code will instruct iOS to display a 'Hello World' message on screen.
You can try to run the project in the simulator. The behaviour of the app is still the same. When you tap the button, it still doesn't show you any response. The reason is that we haven't made the connection between the button and the code.
Connecting the User Interface with Code
I said before that the beauty of iOS development is the separation of code (.swift file) and user interface (storyboards). But how can we establish the relationship between our source code and the user interface?
To be specific for this demo, the question is:
Swift Mac App Development
- How can we connect the 'Hello World' button in the storyboard with the
showMessage(sender: UIButton)method in theViewControllerclass?
You need to establish a connection between the 'Hello World' button and the showMessage(sender: UIButton) method you've just added, such that the app responds when someone taps the Hello World button.
Now select Main.storyboard to switch back to the Interface Builder. Press and hold the control key of the keyboard, click the 'Hello World' button and drag it to the View Controller icon. Release both buttons (mouse + keyboard) and a pop-up shows the showMessageWithSender: option under Sent Events. Select it to make a connection between the button and showMessageWithSender: action.
Test Your App
That's it! You're now ready to test your first app. Just hit the Run button. If everything is correct, your app should run properly in the simulator. This time, the app displays a welcome message when you tap the Hello World button.
Changing the Button Color
As mentioned before, you do not need to write code to customize a UI control. Here, I want to show you how easy it is to change the properties (e.g. color) of a button.
Select the 'Hello World' button and then click the Attributes inspector under the Utility area. You'll be able to access the properties of the button. Here, you can change the font, text color, background color, etc. Try to change the text color (under Button section) to white and background (scroll down and you'll find it under View section) to red or whatever color you want.
Run the project again and see what you get.
Your Exercise #1
Not only can you change the color of a button, you can modify the font type and size in the Attributes inspector by setting the Font option. Your task is to continue to work on the project and create a user interface like figure 3-23. When a user taps any of the buttons, the app displays the same Hello World message.
To give you some hints, here are the things you will need to work on:
- Resize the 'Hello World' button and change its font size to 70 points. Change its title from Hello World to 👾. To key in emoji characters, you can hold down control+command and then press spacebar.
- Add three more buttons. Each of them has an emoji icon as its title.
- Establish a connection between the buttons and the
showMessage(sender: UIButton)method.
Your Exercise #2
Wouldn't it be great if you can display the meaning of the emoji icon instead of the same 'Hello World' message like what I have shown you in figure 3-2?
You've learned how to use a dictionary to store the meaning of emoji icons. Now try to modify the showMessage(sender: UIButton) method such that it displays the meaning of the emoji icon. I will give you a hint. Here is the code skeleton. Replace the code of your existing showMessage(sender: UIButton) method with the following and fill in the missing code:
This exercise is more difficult than the first one. Try your best to complete it. It is really fun to see that you turn a Hello World app into a simple Emoji Translator.
What's Coming Next
Congratulations! You've built your first iPhone app. It's a simple app, but I believe you already have a better understanding of Xcode and understand how an app is built. It's easier than you thought, right?
Even if you couldn't complete exercise #2, that is completely fine. Don't be discouraged. I have included the solution for your reference. Just keep reading, you will get better and better as you have more coding practices.
In the next chapter, we'll discuss the details of the Hello World app and explain how everything works together.
To continue reading and access the full version of the book, please get the full copy here. You will also be able to access the full source code of the project.
